HzWP LC180-A30



   HzI HzWP LS300-A60 wireless charging system is a wireless power supply device based on magnetic coupling resonance technology. It is designed to provide wireless charging solutions for industrial vehicles equipped with energy storage systems, such as AGVs, AMRs, unmanned forklifts, mobile robots, and other industrial vehicle wireless charging applications. Compared to traditional charging methods, it features waterproofing, no active dust generation, and no metal oxidation, offering advantages in safety, aesthetics, and maintenance-free operation.

   Charging begins simply by parking the vehicle in the charging position. With a non-contact design, the transmitter and receiver coils support IP65 waterproof rating, ensuring your charging needs can be met anywhere. The system minimizes environmental impact and can communicate with your vehicle components via CAN/485 interface to optimize lithium battery charging.



Product Parameters

SN

Parameter Description

Parameter Value

01

Input Voltage

100-240V AC  47-63Hz

02

Input Current

20A Max

03

Output Power

1500W Max

04

Charging Voltage

58V(可适配范围:42-58V)

05

Charging Current

Maximum 25 A

06

Optimal Distance

10-40mm

07

Positioning Deviation

+/– 20 mm

08

Transmitter Controller Protection Level

IP20

09

Coil Protection Level

IP67 Receiver Coil/Transmitter Coil IP67

10

Receiver Controller Protection Level

IP54

11

Communication Protocol

CAN / RS485
